Timex’s M24 movement is a manual wind, zero-jewel, no-date movement used in 2 and 3 hand designs between the 1060s and 1970s. It has a 24 hour power reserve.
Read Timex’s official M24 service manual for M24 service, repair, disassembly and assembly information.
The Timex M24 movement is an evolution of the previous generation M21 and M22 models and is easy to spot as its silver in color as opposed to the previous generations brass models.
Below you can see models in my collection that use the M24 movement. This can help you find donor watches suitable for movement-swaps and spare parts.
Brand: TimexModel: Timex MercuryName: Zodiac (unofficial)Reference: 16052Caliber: M24, manual windYear: 1971Dial Code: 16052 271Case: Chrome platedDial: White with blue zodiac symbols, black printed markers, made in Great BritainHands black, stick, unlumedLug Width:18 mm This Timex Zodiac watch can not be…
Brand: TimexModel: Timex MarlinReference: 27290Caliber: M24, Manual wind, no-dateYear: 1980Case: Gold plated base metalDial: Roman numeralsHands: Leaf, no sweeping seconds
Brand: TimexModel: Timex SpriteReference: 22270Caliber: M24Year: 1980Dial Code: 22270 02480Case: Chrome platedLug Width: 16 mm The closest reference for this vintage Timex sprite is an image in a catalog from the following year. This is different having a gold case…
Brand: TimexModel: Timex Mercury (no sweep, no lume)Type: Dress WatchReference: 1030Caliber: M24 Manual WindYear: 1961Dial Code: 1030 2461Case: Chrome platedLug Width: 18mmDial: White with printed arabic markers, no lumeHands: Chrome plated, no lume This vintage Timex mercury from 1961 was…
Brand: TimexModel: Timex Mercury (no sweep, no lume)Type: Dress WatchReference: 1030Caliber: M24 Manual WindYear: 1967Dial Code: 1030 2467Case: Chrome platedLug Width: 18mmDial: White with printed arabic markers, no lume Hands: Chrome plated, no lume This vintage Timex mercury from 1967…
Brand: TimexModel: Timex SpriteType: Kids WatchReference: 1138Caliber: M24, manual windYear: 1969Dial Code: 1138 2469Case: Chrome platedDial: Grey with metallic batton markersHands: ChromedLug Width: 19 mm This vintage Timex Sprite was produced in two variations with the second being a gold…
Brand: TimexModel: Timex SpriteType: Kids WatchReference: 1266Caliber: M24, Manual WindYear: 1969Dial Code: 1266 2469Manufacturered: Great Britain, DundeeCase: Chrome platedDial: Blue with white printed roman numerals, Great BritainHands: WhiteLug Width: 19 mm This vintage Timex Sprite is one of three models…
Brand: TimexModel: Timex Fun TimerType: Ladies / Kids WatchReference: 29001Movement: M24 (Manual Wind)Year: 1973Dial Code: 29001 2473Case: Dupont?Lug Width: 14 mm I was lucky enough to win this vintage 1973 Timex fun timer at a recent eBay auction, and surprised…
Brand: TimexModel: Timex SpriteType: Kids watch / sports watch / dive watchReference: 23270Caliber: M24 (manual wind, no date)Year: 1971Dial Code: 23270 2471Dial: White with lumed markers, 25 metre depth ratingHands: paddle style with lumed endsLug Width: 16 mmCase: chrome platedCase…
Brand: TimexModel: Timex MarlinType: Mens watchReference: 27061Caliber: M24 (manual wind, no date)Year: 1971Dial Code: 27061 2471Case: Chrome plated, bead blastedDial: Green dial with white roman numeralsHands: White stick hands, unlumed.
Brand: TimexModel: Timex SpriteType: Kids WatchReference: 1124Caliber: M24 (Manual Wind)Year: 1970Dial Code: 1124 2470Dial: Blue dial with roman numeralsCase: Gold plated caseHands: White, unlumedLug Width: 18mm
Needs Dial Brand: TimexModel: Timex MercuryMarket: FranceGender: Men’s watchReference: 3086 (Purple Dial)Caliber: M24 (Manual Wind, no date)Year: 1969Dial Code: 3086 2469 (Not present on dial)Manufactured: Great BritainCase: Gold platedDial Markings: Purple with white roman numeralsLug width: 18mmHands: White stick hands.…
Brand: TimexModel: Timex MarlinReference: 26266Caliber: M24 (Manual wind. no date)Year: 1972Dial Code: 26266 2472Case: Gold plated, sunburst patternCrystal: Acrylic, domedLug Width: 18mmDial: Green dial with white printed alternating arabic and stick markersHands: White unlumed stick lands Repairing this watch requires…
![Timex Mercury 3016 2469 [1969]](https://i0.wp.com/www.vintagetimexwatches.com/wp-content/uploads/2023/12/3016-2469-mercurynodate-gold-head-scaled.jpg?fit=768%2C769&ssl=1)
Brand: TimexModel: Timex MercuryMarket: FranceGender: Men’s watchReference: 3016Caliber: M24 (Manual Wind)Year: 1969Dial Code: 3016 2469 (Not present on dial)Manufactured: Great BritainCase: Gold platedDial Markings: Red with white roman numeralsLug width: 18mmHands: White stick hands. No sweeping seconds hand
Brand: TimexModel: Timex SpriteType: Sports / Dive WatchReference: 23270Caliber: M24 (Manual Wind)Year: 1975Dial Code: 23270 02475Case: Chrome platedDial markings: Water resistant, 25 metresLug Width: 16mm
Brand: TimexModel: Timex SpriteReference: 22519Caliber: M24 (Manual Wind)Year: 1980Dial Code: 22519 02480Case: Chrome platedLug Width: 16mmDial Markings: Water Resistant, Arabic numerals
Needs crown Brand: Timex:Model: Timex MercuryReference: 16055Caliber: M24 (Manual wind)Year: 1972Dial Code: 16055 2472Case: Chrome platedLug width: 18mmDial Markings: Breguet style numerals
For repair Brand: TimexModel: Timex SpriteReference: 1157Caliber: M24 (Manual Wind)Year: 1968Dial Code: 1157 2468Case: Chrome platedDial Markings: Waterproof, Arabic numeralsHands: Chrome, LumedLug Width: 16mm (Drilled)
Brand: TimexModel: Timex Skin DiverReference: TBCCaliber: M24 (Manual wind)Year: TBC (1060’s)Case: Stainless SteelDial Markings: 180 MetresBezel: Elapsed TimeLug Width: 18mm
For Repair/Parts Brand: TimexModel: Timex MarlinReference: 26060Caliber: M24 (Manual Wind)Year: 1972Dial Code: 26060 2472Case: Gold platedDial Markings: Waterproof
Brand: TimexModel: Timex SpriteClass: Kids watchReference: 22592Caliber: M24 Manual WindYear: 1990Dial Code: 22592 02490Case: Chrome platedDial Markings: Water ResistantLug Width: 16mm The Timex Sprite reference 22592 is often miss-sold as being a military watch due to it having a black…
Reference: 16059Caliber: M24 (Manual wind, no date)Year: 1975Dial code: 16059 02475Catalog reference: 160.591Model: Timex MercuryDial: RedMarkers: White, printed, italic arabic numeralsHands: White, stickCase: ChromeLug Width: 18mmCase width: TBCCrystal: TBCCompatible crowns: TBC This vintage Timex Mercury watch was manufactured in 1975…
Brand: KeltonRange: Kelton SpriteModel: Kelton Blackjack (Unofficial)Reference: 2317Caliber: M24 (Manual wind, no date)Year: 1971Dial Code: 2317 2471Closest catalog reference: 231.721Dial: White, Blue, BlackDial Markings: WaterproofMarkers: Red/White/ArabicHands: Chrome/Lumed, red sweepCase: Chrome platedLug Width: 16mmCase width: 30mm excluding crownCrystal: TBCCompatible crowns: Any…
![Timex Blackjack [Sprite] 2317-2471 1971](https://i0.wp.com/www.vintagetimexwatches.com/wp-content/uploads/2023/09/2317-2471-sprite-blackjack-head-2.jpg?fit=768%2C768&ssl=1){kind=icon}
Reference: 2317Caliber: M24 (Manual wind, no date)Year: 1971Dial Code: 2317 2471Closest catalog reference: 231.701Model: Timex SpriteNickname: Timex BlackjackCase Width: 30mm excluding crownDial: White, Blue, BlackMarkers: Red/White/ArabicHands: Chrome/Lumed, red sweepCase: Chrome platedLug Width: 16mmCase width: 30mm excluding crownCrystal: TBCCompatible crowns: Most…
For repair Reference: 2251Caliber: M24 (Manual wind, no date)Year: TBCDial Code: 2317 24??Closest catalog reference: TBCModel: Timex SpriteCase Width: TBCDial: ChampagneMarkers: Arabic numeralsDial Markings: Water Resistant, Great BritainHands: Chrome/LumedCase: Chrome platedLug Width: TBCCrystal: TBCCompatible crowns: TBC
Brand: TimexModel: Timex MarlinMovement: M24 (Manual Wind)Year: Unknown – likely 1960’sDial Code: N/ADial Markings: Great Britain This vintage Timex marlin does not feature in any known magazine or advertisement but resembles other marlins produced in the 1960s. This is likely…
If you have this watch for sale working or not let me know [email protected] Model:3020Caliber: M24 (Manual Wind)Year: 1968Dial Code: 3020 2468Range: Timex Fun TimerCase: One piece case, Fixed lugs, Plastic case made from Dupont This watch was supplied in…
Year: 1982Reference: MIL-W-46374BModel: Equivalent Marlin (Later Camper)Movement: M24 (Manual Wind)Complication: Manual Wind, Sweeping Seconds If you trawl eBay and other forums you will see many, usually black dialed watches, labelled as being vintage Timex military watches. In fact there was…
For repair Brand: TimexModel: Timex MarlinReference: 2605 Caliber: M24 (No-date, manual wind with sweeping second hand)Year: 1977Dial Code: 2605 2477Case: Chrome plated base metalComplication: Manual wind movement. Produced in 1977, this vintage Timex Marlin has seen better days. The case…
Year: 1976Reference: 16059 02476Model: Timex MercuryMovement: m24Case: Chrome plated base metalComplication: Manual wind movement.Special Features: Roman numerals
